Aegis Dual Colour Lightbar, 1210mm (47.6″), 72x BLUE/RED LEDs, BLUE COVERS, ECE R10, ECE R65 (TB2/TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06060121 Product Name Aegis DC 1210mm (47.6") - BRB (12VDC) Categories Warning Lamps, Lightbars, Aegis DC Standard, Aegis Dual Colour, Aegis Product Type Products Configurations (available Steady On, Alley Lights, Take-Downs, Traffic Director Dimensions Length 1210mm (48") Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Take-Down Lights (2 heads, Left-Side Alley Light, Hi/Low Power (50%, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Dual Colour Maximum Current 23.3A@12.8VDC Lightbar Length 1210mm (47.6") LED Colour Blue LEDs, Red LEDs Fuse Rating 32A Cover Colour Blue Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), ECE-R65 (TR2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 18.6kg Gross Weight 19.6kg Dummy Bracket Qty 12x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
-
-
-
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Amber LEDs, Blue LEDs
- Linear Optics, T.I.R Optics
-
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Blue LEDs, White LEDs
- Linear Optics, T.I.R Optics
-
-
-
-
-
-
-
-
-
-
Mounting
-
- Downloads
