Specifications
Product Specifications
Product code 02160627 Product Name ST3 (White Bezel) - Blue Categories Warning Lights, ST3, Super Thin, Directionals, Modules Product Type Products Dimensions Length/width 86mm (3.38") Dimensions Height 27mm (1.06") Dimensions Depth 10.6mm (0.41") Bezel Colour White Colour Type Single Colour Maximum Current 0.59A@12VDC / 0.3A@24VDC Storage Temperature -40°C - +75°C Operating Temperature -30°C~+65°C Maximum Power 7.1W Synchronisation 15 Unit Synchronisation LED Colour Blue LEDs Fuse Rating 1A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (XB1) Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Elements 3x LEDs IP Rating IPX8 Flash Patterns 16 Flash Patterns Wire Length 265mm Mounting Orientation Horizontal Gross Weight 0.05kg Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
