Aegis Dual Colour Lightbar, 1210mm (48″), 72LED, BLUE/AMBER, BLACK COVERS, ECE R10, ECE R65 (TA2/TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06060114 Product Name Aegis DC 1210mm (48") - BAK (12VDC) Categories Lighting, Lightbars, Aegis DC Standard, Aegis Dual Colour, Aegis Product Type Products Configurations (available) Take-Downs, Traffic Director, Steady On, Alley Lights Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%), Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Dimensions Width 310mm Colour Type Dual Colour Maximum Current 23.3A@12.8VDC Lightbar Length 1210mm (48") LED Colour Blue/Amber Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA2, ECE R65 - TB2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 12x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
