EAN: 06060022
Aegis Dual Colour Lightbar, 1366mm (53.8″), 72x BLUE/RED LEDs, BLACK COVERS, ECE R10, ECE R65 (TB2/TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06060022 Product Name Aegis DC 1366mm (53.8") - BRK (12VDC) Categories Warning Lights, Aegis DC Standard, Lightbars, Aegis Dual Colour, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Traffic Director, Steady On Dimensions Length/width 1372mm (54") Default Functions Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Take-Down Lights (2 heads, Left-Side Alley Light, Hi/Low Power (50%, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Depth 310mm (12.2") Colour Type Dual Colour Maximum Current 25.3A@12.8VDC Lightbar Length 1366mm (53.8") LED Colour Blue LEDs, Red LEDs Fuse Rating 35A Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), ECE-R65 (TR2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Elements 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 19.6kg Gross Weight 20.6kg Dummy Bracket Qty 14x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lightheads
- Warning
- Dual Colour
- 12x LEDs
- Smaller 3 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Amber LEDs, Blue LEDs
- Linear Optics, T.I.R Optics
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Blue LEDs, Red LEDs
- Linear Optics, T.I.R Optics
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Blue LEDs, White LEDs
- Linear Optics, T.I.R Optics
-
-
-
-
-
-
-
- Lightheads
- Warning
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
-
- Lightheads
- Warning
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
-
-
-
-
Mounting
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable A006)
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable Bolt)
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- Black
- Standard Bolt Mount Brackets
-
