Aegis DC H002 Speaker Lightbar, 1054mm (41.5″), 72LED, RED/BLUE, BLUE COVERS, ECE R10, ECE R65 (TB2/TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06080068 Product Name Aegis DC H002 Speaker 1054mm (41.5") - RBB (12VDC) Categories Lighting, Lightbars, Aegis Dual Colour, Aegis DC H002 Speaker, Aegis Product Type Products Configurations (available) Alley Lights, Take-Downs, Traffic Director Default Functions Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, Hi/Low Power (50%), Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Speaker Power Rating 100W Dimensions Width 310mm Colour Type Dual Colour Maximum Current 21.2A@12.8VDC Lightbar Length 1054mm (41.5") Impedance 10-13 Ohms Speaker Type H002 LED Colour Red/Blue Cover Colour Blue Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB2, ECE R65 - TR2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Wire Length 4800mm Dummy Bracket Qty 6x Dummy Plates Warranty 5 Year Warranty -
