Aegis DC H002 Speaker Lightbar, 1366mm (53.8″), 72x AMBER/BLUE LEDs, BLUE COVERS, ECE R10, ECE R65 (TA2/TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06080143 Product Name Aegis DC H002 Speaker 1366mm (53.8") - ABB (12VDC) Categories Warning Lights, Lightbars, Aegis DC H002 Speaker, Aegis Dual Colour, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Traffic Director Dimensions Length/width 1366mm (54") Default Functions Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Take-Down Lights (2 heads, Hi/Low Power (50%, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Speaker Power Rating 100W Dimensions Depth 310mm (12.2") Colour Type Dual Colour Maximum Current 25.3A@12.8VDC Lightbar Length 1366mm (53.8") Speaker Impedance 10-13 Ohms Speaker Type H002 LED Colour Amber LEDs, Blue LEDs Fuse Rating 35A Cover Colour Blue Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), ECE-R65 (TB2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power/2 Speaker) LED Elements 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Net Weight 15.6kg Gross Weight 16.6kg Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
-
-
-
-
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Amber LEDs, Blue LEDs
- Linear Optics, T.I.R Optics
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Blue LEDs, White LEDs
- Linear Optics, T.I.R Optics
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Mounting
-
- Downloads
