EAN: 06080150
Aegis DC H002 Speaker Lightbar, 1366mm (53.8″), 72x AMBER/BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TA2/TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06080150 Product Name Aegis DC H002 Speaker 1366mm (53.8") - ABK (12VDC) Categories Warning Lights, Lightbars, Aegis Dual Colour, Aegis DC H002 Speaker, Aegis Product Type Products Dimensions Length/width 1366mm (54") Dimensions Height 83mm (3.25") Speaker Power Rating 100W Dimensions Depth 310mm (12.2") Colour Type Dual Colour Fuse Rating 35A Maximum Current 25.3A@12.8VDC Lightbar Length 1366mm (53.8") Speaker Impedance 10-13 Ohms Speaker Type H002 LED Colour Amber LEDs, Blue LEDs Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), ECE-R65 (TB2), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power/2 Speaker) LED Elements 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Net Weight 15.6kg Gross Weight 16.6kg Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Single Colour
- 3x LEDs
- 2 Pin Connector
- Spot Optics
-
- Lightheads
- Dual Colour
- 12x LEDs
- Smaller 3 Pin Connector
- Linear Optics
-
- Lightheads
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
- Spot Optics
-
- Lightheads
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
- Spot Optics
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Linear Optics, T.I.R Optics
- 12VDC
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Linear Optics, T.I.R Optics
- 12VDC
-
- Lightheads
- Dual Layer
- 12x LEDs (6 per Level)
- Linear Optics, T.I.R Optics
- 12VDC
-
-
- Lenses
- Polycarbonate (PC)
- H002
- Middle
- Black Lens
-
-
-
-
-
-
- Lightheads
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
- D-Fuser Optics
-
- Lightheads
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
- D-Fuser Optics
-
-
-
- 100W
- Acrylonitrile Butadiene Styrene (ABS), Aluminium
- 100W
- H002
- 10-13 Ohms
-
-
Mounting
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
-
- Powder-Coated Aluminium
- Black
- MS3 - Extrusion Bracket
-
- Powder-Coated Aluminium
- Black
- MS3 - A006 Mounting Bracket
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable A006)
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable Bolt)
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- Black
- Standard Bolt Mount Brackets
-
