Aegis FIT+ H002 Speaker Lightbar, 1522mm (60″), 36x RED LEDs, BLACK COVERS, ECE R10, ECE R65 (TR2), IPX4K, Firmware (A2), D-Fuser Optics, 7 Flash Patterns, Single Harness (5 Function/2 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
100W low profile built-in speaker.
New optics that meet ECE R65 and ECE R10.
Modern design, with a solid, sturdy look to best fit your vehicle.
3.25″ (83mm) thickness: broad visibility and powerful output.
Take-down, Alley Light: Optional special lighthead.Product Specifications
Product code 06050436 Product Name Aegis FIT+ H002 Speaker 1522mm (60") - RK (12VDC) Categories Lighting, Lightbars, Aegis FIT+, Aegis FIT+ H002 Speaker, Aegis Product Type Products Configurations (available) Alley Lights, Take-Downs, Illuminated Centre, Steady On Default Functions Illuminated Centre Section, Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Take-Down Lights (2 heads, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Speaker Power Rating 100W Dimensions Width 310mm Colour Type Single Colour Maximum Current 17.9A@12.8VDC Lightbar Length 1522mm (60") Impedance 10-13 Ohms Speaker Type H002 LED Colour Red LEDs Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TR2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (5 Function/2 Power/2 Speaker) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Dummy Bracket Qty 12x Dummy Plates Warranty 5 Year Warranty -
