Aegis HE Lightbar, 1054mm (41.5″), 36x AMBER LEDs, AMBER COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030384 Product Name Aegis HE 1054mm (41.5") - AA (24VDC) Categories Lighting, Lightbars, Aegis HE Standard, Aegis High End, Aegis Product Type Products Configurations (available) Alley Lights, Take-Downs, Steady On Default Functions Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Hi/Low Power (50%), Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Dimensions Width 310mm Colour Type Single Colour Lightbar Length 1054mm (41.5") LED Colour Amber LEDs Cover Colour Amber Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Wire Length 4800mm Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
