EAN: 06030025
Aegis HE Lightbar, 1054mm (41.5″), 36x AMBER LEDs, BLACK COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030025 Product Name Aegis HE 1054mm (41.5") - AK (12VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Steady On Dimensions Length 1054mm (42") Default Functions Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, Hi/Low Power (50%, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Single Colour Maximum Current 21.2A@12.8VDC Lightbar Length 1054mm (41.5") LED Colour Amber LEDs Fuse Rating 29A Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 16.6kg Gross Weight 17.6kg Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Single Colour
- 3x LEDs
- 2 Pin Connector
- White LEDs
-
- Lightheads
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
- White LEDs
-
- Lightheads
- Single Colour
- 3x LEDs
- Smaller 3 Pin Connector
- Amber LEDs
-
- Lightheads
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
- Amber LEDs
-
- Lightheads
- Single Colour
- 6x LEDs
- 2x Smaller 3 Pin Connectors
- White LEDs
-
-
- Lenses
- Polycarbonate (PC)
- Middle
- Large, 312mm (12.3")
- Clear Lens
-
-
- Lenses
- Polycarbonate (PC)
- Middle
- Small, 156mm (6.1")
- Clear Lens
-
-
-
-
-
- Lightheads
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
- Amber LEDs
-
- Lightheads
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
- Amber LEDs
-
