EAN: 06030278
Aegis HE Lightbar, 1054mm (41.5″), 36x RED LEDs, BLACK COVERS, ECE R10, ECE R65 (TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030278 Product Name Aegis HE 1054mm (41.5") - RK (12VDC) Categories Warning Lights, Aegis HE Standard, Lightbars, Aegis High End, Aegis Product Type Products Dimensions Length/width 1054mm (42") Dimensions Height 83mm (3.25") Dimensions Depth 310mm (12.2") Colour Type Single Colour Fuse Rating 29A Maximum Current 21.2A@12.8VDC Lightbar Length 1054mm (41.5") LED Colour Red LEDs Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TR2), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Elements 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Net Weight 16.6kg Gross Weight 17.6kg Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
- Spot Optics
-
- Lightheads
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
- Linear Optics
-
- Lightheads
- Single Colour
- 3x LEDs
- 2 Pin Connector
- Spot Optics
-
- Lightheads
- Single Colour
- 6x LEDs
- 2x Smaller 3 Pin Connectors
- 12VDC
-
- Lightheads
- Single Colour
- 3x LEDs
- Smaller 3 Pin Connector
- Fresnel Optics
-
-
-
-
-
-
-
-
-
- Lightheads
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
- D-Fuser Optics
-
- Lightheads
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
- D-Fuser Optics
-
