Aegis HE Lightbar, 1054mm (41.5″), 36x RED LEDs, RED COVERS, ECE R10, ECE R65 (TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030438 Product Name Aegis HE 1054mm (41.5") - RR (24VDC) Categories Lighting, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available) Alley Lights, Take-Downs, Steady On Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Hi/Low Power (50%), Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Dimensions Width 310mm Colour Type Single Colour Lightbar Length 1054mm (41.5") LED Colour Red LEDs Cover Colour Red Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TR2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Wire Length 4800mm Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
