Aegis HE Lightbar, 1366mm (53.8″), 36x AMBER LEDs, BLACK COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030117 Product Name Aegis HE 1366mm (53.8") - AK (12VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Steady On, Alley Lights, Take-Downs Dimensions Length 1372mm (54") Default Functions Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, Hi/Low Power (50%, Left-Side Alley Light, Flashing Alleys & Take-Downs, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Single Colour Maximum Current 25.3A@12.8VDC Lightbar Length 1366mm (53.8") LED Colour Amber LEDs Fuse Rating 35A Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 19.6kg Gross Weight 20.6kg Dummy Bracket Qty 14x Dummy Plates Warranty 5 Year Warranty -
