Aegis HE Lightbar, 1522mm (59.9″), 36x AMBER LEDs, AMBER COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030148 Product Name Aegis HE 1522mm (59.9") - AA (12VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Steady On, Alley Lights, Take-Downs Dimensions Length 1522mm (60") Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, Hi/Low Power (50%, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Single Colour Maximum Current 27.3A@12.8VDC Lightbar Length 1522mm (59.9") LED Colour Amber LEDs Fuse Rating 37A Cover Colour Amber Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 20.6kg Gross Weight 21.6kg Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
