Aegis HE Lightbar, 1522mm (59.9″), 36x RED LEDs, RED COVERS, ECE R10, ECE R65 (TR2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030322 Product Name Aegis HE 1522mm (59.9") - RR (12VDC) Categories Warning Lights, Aegis HE Standard, Aegis High End, Lightbars, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Steady On Dimensions Length/width 1522mm (60") Default Functions Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%, Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Depth 310mm (12.2") Colour Type Single Colour Maximum Current 27.3A@12.8VDC Lightbar Length 1522mm (59.9") LED Colour Red LEDs Fuse Rating 37A Cover Colour Red Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TR2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Elements 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 20.6kg Gross Weight 21.6kg Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
