Aegis HE Lightbar, 1678mm (66.1″), 36x BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030216 Product Name Aegis HE 1678mm (66.1") - BK (12VDC) Categories Warning Lamps, Aegis HE Standard, Aegis High End, Lightbars, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Steady On Dimensions Length 1678mm (66") Default Functions Hi/Low Power (50%, Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Traffic Director - Rear Left Arrow., ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Single Colour Maximum Current 29.3A@12.8VDC Lightbar Length 1678mm (66.1") LED Colour Blue LEDs Fuse Rating 40A Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 22.6kg Gross Weight 23.6kg Dummy Bracket Qty 18x Dummy Plates Warranty 5 Year Warranty -
