Aegis HE H002 Speaker Lightbar, 1678mm (66″), 36x AMBER LEDs, AMBER COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06070182 Product Name Aegis HE H002 Speaker 1678mm (66") - AA (12VDC) Categories Lighting, Lightbars, Aegis High End, Aegis HE H002 Speaker, Aegis Product Type Products Configurations (available) Alley Lights, Take-Downs Default Functions Take-Down Lights (2 heads, Hi/Low Power (50%), Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Speaker Power Rating 100W Dimensions Width 310mm Colour Type Single Colour Maximum Current 29.3A@12.8VDC Lightbar Length 1678mm (66") Impedance 10-13 Ohms Speaker Type H002 LED Colour Amber LEDs Cover Colour Amber Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Dummy Bracket Qty 14x Dummy Plates Warranty 5 Year Warranty -
