EAN: 06070250
Aegis HE H002 Speaker Lightbar, 1834mm (72″), 36x BLUE LEDs, BLUE COVERS, ECE R10, ECE R65 (TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06070250 Product Name Aegis HE H002 Speaker 1834mm (72") - BB (12VDC) Categories Lighting, Lightbars, Aegis High End, Aegis HE H002 Speaker, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs Default Functions Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Take-Down Lights (2 heads, Hi/Low Power (50%), ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Speaker Power Rating 100W Dimensions Width 310mm Colour Type Single Colour Maximum Current 31.3A@12.8VDC Lightbar Length 1834mm (72") Speaker Impedance 10-13 Ohms Speaker Type H002 LED Colour Blue LEDs Cover Colour Blue Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB2, SAE J845 Class 1, California Title 13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lighthead
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lighthead
- Take-Down
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
-
- Lighthead
- Warning
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
-
- Lighthead
- Warning
- Single Colour
- 3x LEDs
- Smaller 3 Pin Connector
-
-
-
-
- Base Plate
- Polycarbonate (PC)
- H002
- Middle
- Large, 312mm (12.3")
-
-
-
-
-
- Lighthead
- Warning
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
-
- Lighthead
- Warning
- Single Colour
- 9x LEDs
- Smaller 3 Pin Connector
-
- 100W
- Acrylonitrile Butadiene Styrene (ABS), Aluminium
- 100W
- H002
- 10-13 Ohms
-
-
