Specifications
Non-volatile memory recalls last flash pattern used at power up.
LEDs rated to 100,000 hours of operation.
Aluminium extrusion for heat dissipation.
Reverse polarity protection.
Waterproof connectors.Product Specifications
Product code 01030105 Product Name Commander SE4 Traffic Director (8 Lighthead) - A8 Categories Warning Lights, Commander SE4, Traffic Advisors Product Type Products Dimensions Length/width 1173mm (46.18") Dimensions Height 46mm (1.80") Dimensions Depth 57mm (2.25") Material Colour Black Colour Type Single Colour Maximum Current 4.16A@12.8VDC / 2.08A@24VDC Operating Temperature -30°C~+65°C Traffic Advisor Length 1173mm (46.2") LED Colour Amber LEDs Traffic Director Functions Traffic Arrow, Warning Mode, End Flashers Lens Colour Clear Lens Compliance ECE-R10 Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Cable Type 1 Cable Harness (6 Function/2 Power) LED Elements 32x LEDs Lighthead Quantity 8x Lightheads Warranty 5 Year Warranty IP Rating IP67 Net Weight 4.15kg Gross Weight 4.35kg -
Spare Parts
-
- Chassis
- Single Colour
- Traffic Arrow, Warning Mode, End Flashers
- 2 Pin Connector
- 12VDC~24VDC
-
- Power Harness, End Caps
- 12VDC~24VDC
- 1 Cable Harness (6 Function/2 Power)
-
-
-
Mounting
-
- Powder-Coated Aluminium
- Surface Mount (Horizontal)
-
-
- Powder-Coated Aluminium
- Angle Adjustable Bracket
-
