Legion FIT Lightbar, 1387mm (54.6″), 24x AMBER LEDs, AMBER LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 7 Flash Patterns, 1 Cable Harness (2 Function/2 Power), Standard Feet, 12~24VDC.
-
Specifications
Built-in selectable flash patterns.
Easy maintenance and lighthead replacement.
Multi-voltage input 12-24VDC with EMC compliance.
Non-volatile memory recalls last flash pattern used at power up.
Solid aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06330095 Product Name Legion FIT 1387mm (54.6") - AA (12~24VDC) Categories Warning Lights, Lightbars, Legion FIT Standard, Legion, Legion FIT Product Type Products Dimensions Length/width 1387mm (54 Dimensions Height 59mm (2.3") Dimensions Depth 331mm (13") Colour Type Single Colour Maximum Current 8.9A@12.8VDC / 4.9A@25.6VDC Lightbar Length 1387mm (54.6") LED Colour Amber LEDs Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (TA1), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC~24VDC Mounting Option Standard Bolt Mount Brackets Cable Type 1 Cable Harness (2 Function/2 Power/2 Speaker) LED Elements 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Net Weight 11.4kg Gross Weight 12.4kg Warranty 5 Year Warranty -
