EAN: 06330460
Legion FIT Lightbar, 2138mm (84.2″), 24x BLUE LEDs, BLUE LENSES, ECE R10, ECE R65 (TB1), IPX4K, D-Fuser Optics, 7 Flash Patterns, 1 Cable Harness (2 Function/2 Power), Standard Feet, 12~24VDC.
-
Specifications
Built-in selectable flash patterns.
Easy Maintenance and lighthead replacement.
Multi-voltage input 12-24VDC with EMC compliance.
Non-volatile memory recalls last flash pattern used at power up.
Solid Aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06330460 Product Name Legion FIT 2138mm (84.2") - BB (12~24VDC) Categories Warning Lights, Legion FIT Standard, Lightbars, Legion FIT, Legion Product Type Products Dimensions Length/width 2138mm (84") Dimensions Height 59mm (2.3") Dimensions Depth 331mm (13") Colour Type Single Colour Maximum Current 12.9A@12.8VDC / 7.4A@25.6VDC Lightbar Length 2138mm (84.2") LED Colour Blue LEDs Lens Colour Blue Lens Compliance ECE-R10, ECE-R65 (TB1), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC~24VDC Mounting Option Standard Bolt Mount Brackets Cable Type 1 Cable Harness (2 Function/2 Power/2 Speaker) LED Elements 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Net Weight 19kg Gross Weight 20kg Warranty 5 Year Warranty -
Spare Parts
-
-
- Lightheads
- Single Colour
- 3x LEDs
- 3 Pin Connector
- Fresnel Optics
-
-
-
-
-
-
- Lightheads
- Single Colour
- 6x LEDs
- 3 Pin Connector
- D-Fuser Optics
-
-
-
Accessories
-
- Roof Connectors
- 4 Pin Connector
- Black
- 1 Cable Harness (2 Function/2 Power)
-
-
Mounting
-
- Downloads
