Legion FIT H002 Speaker Lightbar, 0935mm (37″), 24x BLUE LEDs, CLEAR LENSES, ECE R10, ECE R65 (TB1), IPX4K, D-Fuser Optics, 7 Flash Patterns, Single Harness (2 Function/2 Power/2 Speaker), Standard Feet, 12-24VDC.
-
Specifications
Built-in integrated speaker.
Built-in selectable flash patterns.
Easy maintenance and lighthead replacement.
Multi-voltage input 12-24VDC with EMC compliance.
Non-volatile memory recalls last flash pattern used at power up.
Solid aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06370145 Product Name Legion FIT H002 Speaker 0935mm (37") - BC (12-24VDC) Categories Lighting, Lightbars, Legion FIT H002 Speaker, Legion, Legion FIT Product Type Products Configurations (available) Cruise Light Default Functions Hi/Low Power (50%), ECE-R65 Warning Mode Dimensions Height 77mm Speaker Power Rating 100W Dimensions Width 331mm Colour Type Single Colour Maximum Current 4.8A@12.8VDC / 2.5A@25.6VDC Lightbar Length 0935mm (37") Impedance 10-13 Ohms Speaker Type H002 LED Colour Blue LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB1, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12-24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (2 Function/2 Power/2 Speaker) LED Quantity 24LED Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Wire Length 5000mm Warranty 5 Year Warranty -
