Legion FIT+ Lightbar, 0935mm (36.8″), 24x AMBER LEDs, AMBER/OPAL LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 7 Flash Patterns, Single Harness (8 Function/2 Power), Standard Feet, 12-24VDC.
-
Specifications
LEDs rated to 100,000 hours of operation.
Easy maintenance and lighthead replacement.
Optional Takedowns and Alley Lights are available.
D-Fuser optics for superior 360 degree light spread.
Non-volatile memory recalls last flash pattern used at power up.
Aluminium extrusion for best heat dissipation.
Built-in and programmable flashing patterns.
Reverse polarity protection.Product Specifications
Product code 06270391 Product Name Legion FIT+ 0935mm (37") - AAO (12-24VDC) Categories Lightbars, Legion FIT+ Standard, Legion, Legion FIT+ Product Type Products Configurations (available) Steady On, Cruise Light, Alley Lights, Take-Downs, Illuminated Centre Default Functions ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm Dimensions Width 331mm Colour Type Single Colour Maximum Current 6.5A@12.8VDC / 3.4A@25.6VDC Operating Temperature -30°C to +65°C Lightbar Length 0935mm (37") LED Colour Amber LEDs Lens Colour Amber Lens, Opal Lens Compliance ECE R10, ECE R65 - TA1 Optic Type D-Fuser Optics Nominal Voltage 12-24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (8 Function/2 Power) LED Quantity 24LED Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Warranty 5 Year Warranty -
