EAN: 06270131
MPN: LFIT+093RC-STD
Legion FIT+ Lightbar, 0935mm (36.8″), 24x RED LEDs, CLEAR LENSES, ECE R10, ECE R65 (TR1), IPX4K, D-Fuser Optics, 7 Flash Patterns, Single Harness (8 Function/2 Power), Standard Feet, 12-24VDC.
-
Specifications
LEDs rated to 100,000 hours of operation.
Easy maintenance and lighthead replacement.
Optional Takedowns and Alley Lights are available.
D-Fuser optics for superior 360 degree light spread.
Non-volatile memory recalls last flash pattern used at power up.
Aluminium extrusion for best heat dissipation.
Built-in and programmable flashing patterns.
Reverse polarity protection.Product Specifications
Product code 06270131 Product Name Legion FIT+ 0935mm (37") - RC (12-24VDC) Categories Lightbars, Legion FIT+ Standard, Legion, Legion FIT+ Product Type Products Configurations (available) Cruise Light, Alley Lights, Take-Downs, Steady On Default Functions ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm Dimensions Width 331mm Colour Type Single Colour Maximum Current 6.5A@12.8VDC / 3.4A@25.6VDC Operating Temperature -30°C to +65°C Lightbar Length 0935mm (37") LED Colour Red LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TR1 Optic Type D-Fuser Optics Nominal Voltage 12-24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (8 Function/2 Power) LED Quantity 24LED Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Warranty 5 Year Warranty -
Spare Parts
-
-
-
-
- Lighthead
- Warning
- 3LED
- 3 Pin Connector
- Fresnel Optics
-
- Lighthead
- Take-Down
- 6LED
- 3 Pin Connector
- TIR Optics
-
- Lighthead
- Take-Down
- 6LED
- 3 Pin Connector
- TIR Optics
-
- Lighthead
- Take-Down
- 9LED
- 3 Pin Connector
- TIR Optics
-
- Lighthead
- Take-Down
- 9LED
- 3 Pin Connector
- TIR Optics
-
- Lighthead
- Stop/Tail/Turn (STT)
- ECE R7
- 12LED
- Clear Lens
-
-
-
-
-
- Lighthead
- Warning
- 6LED
- 3 Pin Connector
- D-Fuser Optics
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 9 Pin Connector
- Single Harness (8 Function/2 Power)
-
-
Mounting
-
- Bracket
- Steel
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Steel
- Low Profile Flat Narrow Feet
- Black
-
-
- Bracket
- Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Bracket
- Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Bracket
- Mount Kit (Adjustable A006)
- Black
-
- Bracket
- Steel
- Mount Kit (Adjustable Bolt)
- Black
-
- Bracket
- Steel
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Steel
- Low Profile Flat Narrow Feet
- Black
-
-
