Legion FIT+ Lightbar, 1387mm (54.5″), 24x AMBER LEDs, CLEAR LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12-24VDC.
-
Specifications
LEDs rated to 100,000 hours of operation.
Easy maintenance and lighthead replacement.
Optional takedowns and alley lights are available.
D-Fuser optics for superior 360 degree light spread.
Non-volatile memory recalls last flash pattern used at power up.
Aluminium extrusion for best heat dissipation.
Built-in and programmable flashing patterns.
Reverse polarity protection.Product Specifications
Product code 06270285 Product Name Legion FIT+ 1387mm (54.5") - AC (12-24VDC) Categories Lighting, Lightbars, Legion FIT+ Standard, Legion, Legion FIT+ Product Type Products Configurations (available) Traffic Director, Stop / Tail / Turn, Steady On, Cruise Light, Alley Lights, Take-Downs Default Functions Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Take-Down Lights (2 heads, Program Mode, Hi/Low Power (50%), Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm Dimensions Width 331mm Colour Type Single Colour Maximum Current 8.9A@12.8VDC / 4.9A@25.6VDC Operating Temperature -30°C to +65°C Lightbar Length 1387mm (54.5") LED Colour Amber LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA1 Optic Type D-Fuser Optics Nominal Voltage 12-24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 24LED Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 21 Flash Patterns Warranty 5 Year Warranty -
