Legion FIT+ H002 Speaker Lightbar, 1537mm (60.5″), 24x AMBER LEDs, CLEAR LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12-24VDC.
-
Specifications
Product Specifications
Product code 06220167 Product Name Legion FIT+ H002 Speaker 1537mm (60.5") - AC (12-24VDC) Categories Lighting, Lightbars, Legion FIT+ H002 Speaker, Legion, Legion FIT+ Product Type Products Configurations (available) Cruise Light, Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On Default Functions ECE-R65 Warning Mode Dimensions Height 77mm Speaker Power Rating 100W Dimensions Width 331mm Colour Type Single Colour Operating Temperature -30°C to +65°C Siren Output Power 100W Lightbar Length 1537mm (60.5") Impedance 10-13 Ohms LED Colour Amber LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA1, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12-24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 24LED Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Warranty 5 Year Warranty -
