EAN: 06260262
Legion HE H002 Speaker Lightbar, 1537mm (60.5″), 72x AMBER LEDs, AMBER LENSES, ECE R10, ECE R65 (TA2), IPX4K, D-Fuser Optics, 12 Flash Patterns, 2 Cable Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
Product Specifications
Product code 06260262 Product Name Legion HE H002 Speaker 1537mm (60.5") - AA (12VDC) Categories Warning Lights, Legion High End, Lightbars, Legion HE H002 Speaker, Legion Product Type Products Dimensions Length 1537mm (60") Default Functions Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Take-Down Lights (2 heads, Left-Side Alley Light, Hi/Low Power (50%, Flashing Alleys & Take-Downs, Front Cut-Off, Steady On, Rear Cut-Off, Program Mode, Control Box Transmission Line, Stop / Tail / Turn, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Speaker Power Rating 100W Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Single Colour Lightbar Length 1537mm (60.5") Speaker Impedance 10-13 Ohms LED Colour Amber LEDs Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (TA2), SAE J595 Class 1, SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Dummy Bracket Qty 8x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
-
- Lightheads
- Warning
- Single Colour
- 3 Pin Connector
- D-Fuser Optics
-
- 100W
- Acrylonitrile Butadiene Styrene (ABS), Aluminium
- 100W
- H002
- 10-13 Ohms
-
-
-
-
-
- Lightheads
- Warning
- Single Colour
- 3 Pin Connector
- D-Fuser Optics
-
- Lightheads
- Warning
- Single Colour
- 3 Pin Connector
- D-Fuser Optics
-
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 9 Pin Connector
- 1 Cable Harness (8 Function/2 Power)
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
