Specifications
Super low profile for discreet mounting.
Weatherproof and vibration resistant design for internal or external use.
Non-volatile memory recalls last flash pattern used at power up.
LEDs rated to 100,000 hours of operation.
Meet’s ECE R10, SAE class 1 compliance.
Built-in 5 selectable flash patterns.
Multiple units are synchronizable.
Multi-Voltage Input 12~24VDC.
Reverse polarity protection.
Aluminium heat dissipation.Product Specifications
Product code 02040196 Product Name MS6 Warning Module (Hood/Horizontal) - White Categories Directionals, MS6, Mini Stealth, Modules Product Type Products Dimensions Length 107mm (4.2") Dimensions Height 24mm (0.94") Dimensions Width 42mm (1.65") Bezel Colour Black Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 1.15A@12VDC / 0.58A@24VDC Operating Temperature -30°C~+65°C Maximum Power 13.8W Synchronisation 15 Unit Synchronisation LED Colour White LEDs Fuse Rating 2A Lens Colour Clear Lens Compliance ECE-R10, SAE J595 Class 1, SAE J845 Class 1 Optic Type T.I.R Optics Input Voltage 12VDC~24VDC Mounting Option Hood Mount Cable Type Cable (Pigtail) LED Quantity 6x LEDs IP Rating IP67 Flash Patterns 19 Flash Patterns Wire Length 970mm Mounting Orientation Horizontal Gross Weight 0.20kg Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
Mounting
-
- Downloads
