Warning models certified with SAE J595, SAE J845 Class 1, CA Title 13 and meet NFPA1901 and KKK1822 compliance when configured correctly.
Choose from 16 built-in flash patterns in solid, left-right split, top-bottom split, or criss-cross split flash mode.
Multi-units synchronization in simultaneous or alternating flash.
Reverse polarity protection.
Weatherproof and vibration resistant design for internal or external use.
Solid aluminium base for efficient heat dissipation.
Product code 02200019 Product Name R4 - AA Categories Warning Lights, R4 Responder, Modules, Responder Product Type Products Dimensions Length/width 139mm (5.48") Dimensions Height 76mm (3") Dimensions Depth 22.5mm (0.89") Bezel Colour Black Colour Type Single Colour Maximum Current 1.81A@12VDC / 0.91A@24VDC Storage Temperature -40°C - +75°C Operating Temperature -30°C~+65°C Maximum Power 21.7W Synchronisation 15 Unit Synchronisation LED Colour Amber LEDs Fuse Rating 2A Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (XA2), SAE J595 Class 1, SAE J845 Class 1 Input Voltage 12VDC~24VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Elements 8x LEDs IP Rating IPX7 Flash Patterns 16 Flash Patterns Wire Length 250mm Mounting Orientation Horizontal Gross Weight 0.20kg Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty
