Specifications
Die-cast aluminium base for efficient heat dissipation and high LED durability.
Over 1730 lumen output; Luminous intensity ëº 820 lux at 1 meter.
Curved design to maximize coverage with streamline aesthetics.
Weatherproof and vibration resistant design for external use.
Certified ECE R10 and CISPR 25 Class 3.
Reverse polarity protection.Product Specifications
Product code 07040085 Product Name SL209 Scene Light - White (Housing - White) Categories SL209 Exterior Scene Light, Scene Lamps, Illumination Product Type Products Dimensions Length 227mm Dimensions Height 62mm Dimensions Width 42mm Colour Type Single Colour Maximum Current 1.12A@12VDC / 0.56A@24VDC Storage Temperature -40°C to +75°C Operating Temperature -40°C to +60°C Maximum Power 13.44W LED Colour White LEDs Fuse Rating 1.5A Lens Colour Clear Lens Compliance ECE R10, CISPR25 Nominal Voltage 12-24VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Quantity 6LED IP Rating IPX7 Wire Length 210mm Mounting Orientation Horizontal Raw Lumens 1730lm Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty - Downloads
