Specifications
Independent Cruise Mode that allows two colour selection.
Ultra-bright dual colour lighthead with ECE R65 Class 2 approval.
Measuring 0.5″Ø (13.1mm) in depth, this lighthead is highly versatile for application to any vehicle.
Multi memories design for instant switch between selected flash patterns and/or colours.
Weatherproof and vibration resistant design for internal or external use.
Non-Volatile memory recalls last flash pattern used at power up.
Multi-units synchronization is simultaneous or alternating flash.
Die-cast aluminium base for heat dissipation.
Reverse polarity protection.Product Specifications
Product code 02210063 Product Name SM6 Warning Lighthead (Dual Colour) - Red/White Categories Lighting, Directionals, Modules, StealthMax Product Type Products Default Functions Steady On, Hi/Low Power (50%), Cruise Light Mode, ECE-R65 Warning Mode Dimensions Length 137mm Dimensions Height 42mm Dimensions Width 13mm Bezel Colour Black Colour Type Dual Colour Maximum Current 1.35A@12VDC / 0.68A@24VDC Storage Temperature -40°C to +75°C Operating Temperature -30°C to +65°C Maximum Power 16.2W Synchronisation 20 Unit Sync LED Colour Red/White Fuse Rating 2A Lens Colour Clear Lens Compliance ECE R10, ECE R65 - XR2, CISPR25, SAE J595 Class 1 Nominal Voltage 12-24VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Quantity 12LED IP Rating IPX7 Flash Patterns 28 Flash Patterns Wire Length 210mm Mounting Orientation Horizontal Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
