Specifications
Up to 49 Amp for warning lights, siren, work lights and auxiliary devices.
3 inputs for Siren Park Kill, external buttons, signal detection and ignition detection application.
8-button control panel with two-colour backlight, build-in Buzzer and 10 indicator LED for traffic arrow.
Programmable function for European Siren Interlock, Traffic Arrow or Scene buttons for quick activation.
Entering Standby Mode automatically after the controller has been inactivated for 1 or 15 minutes.Product Specifications
Product code 12060092 Product Name SW833 Control Panel & Power Module (Permanent Mount) Categories Electronic Equipment, SW833 Control Panel & Power Module, Control Systems Product Type Products Storage Temperature -40°C to +75°C Operating Temperature -40°C to +60°C Switch Current Max 45A / Standby Current 35mA Fuse Rating 50A Compliance ECE R10 Nominal Voltage 12-24VDC Mounting Option 2-Bolt Mount Cable Type Cable (Straight) Wire Length 4000mm Indicator LEDs LED Indicators x10 Switch Quantity 8x Buttons -
