EAN: 06150914
Torrent Lightbar, 1252mm (49.3″), 48x RED LEDs, RED LENSES (LONG), ECE R10, IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Integrated take-down light and alley light options.
Solid aluminium body for best durability and heat dissipation.
Programmable flash patterns with optional traffic arrow and stop/tail/turn function.
Reverse polarity protection.
ECE R10 EMC Compliance.Product Specifications
Product code 06150914 Product Name Torrent 1252mm (49.3") - RR (Long Lens/24VDC) Categories Warning Lamps, Torrent Single Colour, Lightbars, Torrent Product Type Products Configurations (available Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On, Cruise Light, Alley Lights, Take-Downs Default Functions Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Illuminated Centre Section, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Traffic Director - Rear Left Arrow., Hi/Low Power (50%, Traffic Director - Rear Right Arrow., Stop / Tail / Turn, Control Box Transmission Line, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm (2.6") Dimensions Width 317mm (12.4") Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 11.4A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1252mm (49.3") LED Colour Red LEDs Fuse Rating 20A Lens Colour Red Lens Compliance ECE-R10, SAE J845 Class 1, CA13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 14 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Gross Weight 16.4kg Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Single Colour
- 3x LEDs
- 2 Pin Connector
- White LEDs
-
- Lightheads
- Single Colour
- 6x LEDs
- 3 Pin Connector
- Red LEDs
-
- Dummy Brackets
- Powder-Coated Aluminium
- Black
- Middle Lighthead
-
-
-
-
-
-
- Lightheads
- Single Colour
- 12x LEDs
- 3 Pin Connector
- Red LEDs
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- Standard Bolt Mount Brackets
- Black
-
