EAN: 06151270
Torrent Lightbar, 1372mm (54″), 48x BLUE LEDs, CLEAR LENSES (SHORT), ECE R10, ECE R65 (TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
Integrated take-down light and alley light options.
Solid aluminium body for best durability and heat dissipation.
Programmable flash patterns with optional traffic arrow and stop/tail/turn function.
Reverse polarity protection.
ECE R10 EMC Compliance.Product Specifications
Product code 06151270 Product Name Torrent 1372mm (54") - BC (Short Lens/12VDC) Categories Warning Lights, Lightbars, Torrent Single Colour, Torrent Product Type Products Configurations (available Take-Downs, Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On, Cruise Light, Alley Lights Default Functions Hi/Low Power (50%, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Illuminated Centre Section, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Stop / Tail / Turn, Control Box Transmission Line, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm (2.6") Dimensions Depth 317mm (12.4") Colour Type Single Colour Maximum Current 25.6A@12.8VDC Storage Temperature -40°C - +75°C Operating Temperature -30°C~+65°C Lightbar Length 1372mm (54") LED Colour Blue LEDs Fuse Rating 40A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Elements 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 14 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Gross Weight 16.4kg Dummy Bracket Qty 18x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lightheads
- Warning
- Single Colour
- 6x LEDs
- 3 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 6x LEDs
- 2 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 9x LEDs
- 2 Pin Connector
-
- Dummy Brackets
- Powder-Coated Aluminium
- Black
- Middle Lighthead
-
-
-
-
-
-
- Lightheads
- Warning
- Single Colour
- 12x LEDs
- 3 Pin Connector
-
-
Mounting
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable A006)
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable Bolt)
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- Black
- Standard Bolt Mount Brackets
-
