Torrent Dual Colour Lightbar, 1132mm (44.5″), 48LED, RED/BLUE, CLEAR LENSES (SHORT), ECE R10, IPX4K, D-Fuser Optics, 21 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Aerodynamic shape for minimum air resistance and wind shear.
Low-profile design, with a solid, sturdy look to best fit your vehicle.
New linear D-fuser technology with powerful SAE/CA13/ECE R10 approved performance.
Solid top and base aluminium plates for best rigidity and heat dissipation.
Built-in rear traffic director function.ShortProduct Specifications
Product code 06170196 Product Name Torrent DC 1132mm (44.5") - Red/Blue (Short Lens/24VDC) Categories Lighting, Lightbars, Torrent Dual Colour, Torrent Product Type Products Configurations (available) Take-Downs, Traffic Director, Illuminated Centre, Steady On, Cruise Light, Alley Lights Default Functions Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Hi/Low Power (50%), Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm Dimensions Width 317mm Colour Type Dual Colour Maximum Current 8.4A@25.6VDC Operating Temperature -30°C to +65°C Lightbar Length 1132mm (45') LED Colour Red/Blue Fuse Rating 20A Lens Colour Clear Lens Compliance ECE R10, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 17 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 14x Dummy Plates Warranty 5 Year Warranty -
