EAN: 06170233
Torrent Dual Colour Lightbar, 1252mm (49.3″), 48x BLUE/RED LEDs, CLEAR LENSES (SHORT), ECE R10, IPX4K, D-Fuser Optics, 21 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Aerodynamic shape for minimum air resistance and wind shear.
Low-profile design, with a solid, sturdy look to best fit your vehicle.
New linear D-fuser technology with powerful SAE/CA13/ECE R10 approved performance.
Solid top and base aluminium plates for best rigidity and heat dissipation.
Built-in rear traffic director function.Product Specifications
Product code 06170233 Product Name Torrent DC 1252mm (49.3") - BR (Short Lens/24VDC) Categories Warning Lights, Lightbars, Torrent Dual Colour, Torrent Product Type Products Configurations (available Cruise Light, Alley Lights, Take-Downs, Traffic Director, Illuminated Centre, Steady On Default Functions Hi/Low Power (50%, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm (2.6") Dimensions Depth 317mm (12.4") Colour Type Dual Colour Maximum Current 9.2A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1252mm (49.3") LED Colour Blue LEDs, Red LEDs Fuse Rating 20A Lens Colour Clear Lens Compliance ECE-R10, SAE J845 Class 1, CA13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Elements 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 17 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Gross Weight 16.4kg Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 6x LEDs
- 2 Pin Connector
-
- Lightheads
- Take-Down
- Single Colour
- 9x LEDs
- 2 Pin Connector
-
- Lightheads
- Warning
- Dual Colour
- 6x LEDs
- 3 Pin Connector
-
- Dummy Brackets
- Powder-Coated Aluminium
- Black
- Middle Lighthead
-
-
-
-
-
-
- Lightheads
- Warning
- Dual Colour
- 12x LEDs
- 3 Pin Connector
-
-
Mounting
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable A006)
-
- Powder-Coated Aluminium
- Black
- Mount Kit (Adjustable Bolt)
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Wide Feet
-
- Powder-Coated Aluminium
- Black
- Low Profile Flat Narrow Feet
-
- Powder-Coated Aluminium
- Black
- Standard Bolt Mount Brackets
-
