EAN: 06170127
MPN: TDC.137S.ABC-STD
Torrent Dual Colour Lightbar, 1372mm (54″), 48LED, BLUE/AMBER, CLEAR LENSES (SHORT), ECE R10, IPX4K, D-Fuser Optics, 21 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
Aerodynamic shape for minimum air resistance and wind shear.
Low-profile design, with a solid, sturdy look to best fit your vehicle.
New linear D-fuser technology with powerful SAE/CA13/ECE R10 approved performance.
Solid top and base aluminium plates for best rigidity and heat dissipation.
Built-in rear traffic director function.Product Specifications
Product code 06170127 Product Name Torrent DC 1372mm (54") - Blue/Amber (Short Lens/12VDC) Categories Lighting, Lightbars, Torrent Dual Colour, Torrent Product Type Products Configurations (available) Take-Downs, Traffic Director, Illuminated Centre, Steady On, Cruise Light, Alley Lights Default Functions Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Take-Down Lights (2 heads, Rear Cut-Off, Hi/Low Power (50%), Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm Dimensions Width 317mm Colour Type Dual Colour Maximum Current 19.9A@12.8VDC Operating Temperature -30°C to +65°C Lightbar Length 1372mm (54") LED Colour Blue/Amber Fuse Rating 40A Lens Colour Clear Lens Compliance ECE R10, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 17 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 18x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
-
- Lighthead
- Warning
- 6LED
- 3 Pin Connector
- Clear Lens
-
- Lighthead
- Take-Down
- 6LED
- 2 Pin Connector
- TIR Optics
-
- Lighthead
- Take-Down
- 9LED
- 2 Pin Connector
- TIR Optics
-
-
-
-
-
-
- Lighthead
- Warning
- 12LED
- 3 Pin Connector
- Clear Lens
-
-
Mounting
-
- Bracket
- Steel
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Steel
- Low Profile Flat Narrow Feet
- Black
-
- Bracket
- Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Bracket
- Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Bracket
- Mount Kit (Adjustable A006)
- Black
-
- Bracket
- Steel
- Mount Kit (Adjustable Bolt)
- Black
-
- Bracket
- Steel
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Steel
- Low Profile Flat Narrow Feet
- Black
-
-
