Specifications
Multi-voltage input 12-24VDC.
LEDs rated to 100,000 hours of operation.
Non-volatile memory recalls last flash pattern used at power up.
Multiple units are synchronizable and can flash simultaneously or alternately.
Weatherproof and vibration resistant for external or internal use.
Reverse polarity protection.Product Specifications
Product code 05190058 Product Name B14 Beacon - AA (DIN Pole Mount) Categories Warning Lights, Beacons, B14 Beacons Product Type Products Dimensions Height 202mm (7.95") Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 3.3A@12VDC / 1.75A@24VDC Operating Temperature -30°C~+65°C Maximum Power 42W Synchronisation 4 Unit Synchronisation Diameter ⌀142mm (5.59") LED Colour Amber LEDs Fuse Rating 5A Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (TA1), SAE J845 Class 1, CA13 Input Voltage 12VDC~24VDC Mounting Option DIN Pole Mount LED Quantity 10x LEDs IP Rating IPX5 Flash Patterns 14 Flash Patterns Gross Weight 0.92kg Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
