Specifications
Non-volatile flash pattern memory.
ECE R10 EMC electromagnetic compatibility.
Newly design LED optic certified ECE R65 rotating beacon.
Weatherproof and shockproof capability for all environment.
Reverse polarity protection.
100,000 hour rated LED.Product Specifications
Product code 05200306 Product Name B16 Revo Beacon - BB (3-Bolt Mount) Categories Warning Lights, Beacons, B16 Revo, B16 Beacons Product Type Products Dimensions Height 80mm (3.15") Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 1.28A@12VDC / 0.64A@24VDC Operating Temperature -30°C~+65°C Maximum Power 15.3W Diameter ⌀142mm (5.59") LED Colour Blue LEDs Fuse Rating 3A Lens Colour Blue Lens (Dark) Compliance ECE-R10, ECE-R65 (TB1) Input Voltage 12VDC~24VDC Mounting Option 3-Bolt Mount Cable Type Cable (Pigtail) LED Quantity 10x LEDs IP Rating IP6K6, IP6K6K Flash Patterns 1 Flash Pattern Wire Length 400mm Gross Weight 0.7kg Conductor Cross-Section 0.75mm² (18AWG) Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
