Specifications
Individual lightheads meet ECE R65 certification.
New Q-lock mechanism provides a tool-free, quick releasing of lightheads for easy replacement.
New Horizon 6LED optics, super low profile with seamless output.
Dual warning memory for instant switch between flash patterns.
Non-volatile memory recalls last flash pattern used at power up.
Solid Aluminium extrusion for heat dissipation.
Steady burn mode as full flood or scene light.
Reverse polarity protection.Product Specifications
Product code 01100082 Product Name Horizon Warning Stick 0243mm - A2 Categories Lighting, Horizon, Horizon (Single Colour), Traffic Advisors Product Type Products Dimensions Height 32mm Dimensions Width 53mm Colour Type Single Colour Maximum Current 1.72A@12VDC / 0.86A@24VDC Storage Temperature -40°C to +75°C Operating Temperature -30°C to +65°C Maximum Power 20.6W Traffic Advisor Length 0243mm LED Colour Amber LEDs Fuse Rating 2.0A@12VDC / 1.0A@24VDC Lens Colour Clear Lens Traffic Director Functions Warning Mode Compliance ECE R10, ECE R65 - XA1, CISPR25, SAE J595 Class 1, California Title 13 Optic Type Horizon Optics Nominal Voltage 12-24VDC Mounting Option 2-Bolt Mount Cable Type Single Harness (4 Function/2 Power) LED Quantity 12LED Lighthead Quantity 2x Lightheads IP Rating IPX7 Flash Patterns 50 Flash Patterns Wire Length 3000mm Mounting Orientation Horizontal Warranty 5 Year Warranty -
