Specifications
Individual lightheads meet ECE R65 certification.
New Q-lock mechanism provides a tool-free, quick releasing of lightheads for easy replacement.
New Horizon 6LED optics, super low profile with seamless output.
Dual warning memory for instant switch between flash patterns.
Non-volatile memory recalls last flash pattern used at power up.
Solid Aluminium extrusion for heat dissipation.
Steady burn mode as full flood or scene light.
Reverse polarity protection.Product Specifications
Product code 01100075 Product Name Horizon Warning Stick (2 Lighthead) - R2 Categories Warning Lights, Horizon, Horizon (Single Colour), Traffic Advisors Product Type Products Dimensions Height 32mm (1.26") Dimensions Width 53.4mm (2.1") Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 1.72A@12VDC / 0.86A@24VDC Operating Temperature -30°C~+65°C Maximum Power 20.6W Traffic Advisor Length 0243mm (9.6") LED Colour Red LEDs Fuse Rating 2.0A@12VDC / 1.0A@24VDC Traffic Director Functions Warning Mode Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (XR1), CISPR25, SAE J595 Class 1, CA13 Optic Type Horizon Optics Input Voltage 12VDC~24VDC Mounting Option 2-Bolt Mount Cable Type 1 Cable Harness (4 Function/2 Power) LED Quantity 12x LEDs Lighthead Quantity 2x Lightheads IP Rating IPX7 Flash Patterns 50 Flash Patterns Wire Length 3000mm Mounting Orientation Horizontal Gross Weight 1.25kg Warranty 5 Year Warranty -
