Legion Dual Colour Lightbar, 1087mm (43″), 64x BLUE/AMBER LEDs, CLEAR LENS, ECE R10, ECE R65 (TA1/TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Integrated Take-down Light and Alley Light options.
Full dual colour lightheads for instant change between colours.
New improved D-Fuser optic with SAE Class 1 and ECE R65 certified performance.
Solid aluminium base plate for best rigidity and heat dissipation.
Long life LEDs technology rated to 100,000 hours of operation.
Reverse polarity protection.Product Specifications
Product code 06360092 Product Name Legion DC 1087mm (43") - Blue/Amber (24VDC) Categories Lighting, Legion Dual Colour Standard, Lightbars, Legion Dual Colour, Legion Product Type Products Configurations (available) Cruise Light, Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn, Steady On Default Functions Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%), Right-Side Alley Light, Left-Side Alley Light, Steady On, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm Dimensions Width 331mm Colour Type Dual Colour Maximum Current 8.4A@25.6VDC Operating Temperature -30°C to +65°C Lightbar Length 1087mm (43") LED Colour Blue/Amber Software Version (Default) CA Software (16 Wire Modes, 4 Power Wires, 2 Cable Harness Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA1, ECE R65 - TB2, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 24VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 64x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
