Legion Dual Colour Lightbar, 1087mm (42.8″), 48x BLUE/WHITE LEDs, CLEAR LENS, ECE R10, ECE R65 (TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet 24VDC.
-
Specifications
Integrated Take-down Light and Alley Light options.
Full dual colour Lightheads for instant change between colours.
New improved D-Fuser Optic with SAE Class 1 and ECE R65 certified performance.
Programmable flash patterns, with optional Traffic Arrow and Stop/Tail/Turn function.
Easy removable dome lens for simple maintenance and lighthead replacement.
21 Programmable flash pattern for each individual Lighthead (pair).
Solid Aluminium base plate for best rigidity and heat dissipation.
Long life LEDs technology rated to 100,000 hours of operation.
Reverse polarity protection.Product Specifications
Product code 06360313 Product Name Legion DC 1087mm (42.8") - BW (24VDC) Categories Lightbars, Legion Dual Colour Standard, Legion Dual Colour, Legion Product Type Products Configurations (available Stop / Tail / Turn, Steady On, Cruise Light, Alley Lights, Take-Downs, Traffic Director Dimensions Length 1087mm (42.8") Default Functions Left-Side Alley Light, Steady On, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%, Right-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Dual Colour Maximum Current 8.4A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1087mm (42.8") LED Colour Blue LEDs, White LEDs Software Version (Default) CA Software (16 Wire Modes, 4 Power Wires, 2 Cable Harness Fuse Rating 20A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, CA13 Optic Type D-Fuser Optics Input Voltage 24VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power/2 Speaker) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 12.4kg Gross Weight 13.4kg Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lightheads
- Warning
- Dual Colour
- 3 Pin Connector
- Xtreme Optics
-
-
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Stop/Tail/Turn (STT)
- ECE-R7
- Split Colour
- Clear Lens
-
-
-
-
-
-
- Lightheads
- Warning
- Dual Colour
- 4 Pin Connector
- D-Fuser Optics
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 9 Pin Connector
- 1 Cable Harness (8 Function/2 Power)
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- Standard Bolt Mount Brackets
- Black
-
