Specifications
Product Specifications
Product code 06230197 Product Name Legion FIT Split Lightbar 0315mm (12.5") x2 - RC Categories Lighting, Lightbars, Legion FIT, Legion, Legion FIT Split Product Type Products Default Functions Hi/Low Power (50%), ECE-R65 Warning Mode Dimensions Height 59mm Dimensions Width 331mm Colour Type Single Colour Maximum Current 7.3A@12.8VDC / 3.9A@25.6VDC Lightbar Length 0315mm (12.5") x2 LED Colour Red LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TR1, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics, Fresnel Optics Nominal Voltage 12-24VDC Mounting Option 8-Bolt Mount Cable Type Single Harness (2 Function/2 Power/2 Speaker) LED Quantity 36x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
