Specifications
Product Specifications
Product code 02040868 Product Name MS6 Warning Lighthead (Hood/Horizontal) - Blue (XB1) - Tinted Categories Directionals, MS6, Mini Stealth, Modules Product Type Products Dimensions Length 107mm (4.2") Dimensions Height 24mm (0.94") Dimensions Width 42mm (1.65") Bezel Colour Black Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 1.15A@12VDC / 0.58A@24VDC Operating Temperature -30°C~+65°C Maximum Power 13.8W Synchronisation 15 Unit Sync LED Colour Blue LEDs Fuse Rating 2A Lens Colour Tinted Lens Compliance ECE-R10, ECE-R65 (XB1) Optic Type T.I.R Optics Input Voltage 12VDC~24VDC Mounting Option Hood Mount Cable Type Cable (Pigtail) LED Quantity 6x LEDs IP Rating IPX7 Flash Patterns 5 Flash Patterns Wire Length 970mm Mounting Orientation Horizontal Gross Weight 0.01kg Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
