Specifications
Product Specifications
Product code 02040882 Product Name MS6 Warning Lighthead (Hood/Vertical) - Blue (XB1) - Tinted Categories Directionals, Mini Stealth, MS6, Modules Product Type Products Dimensions Length 24mm Dimensions Height 107mm Dimensions Width 42mm Bezel Colour Black Colour Type Single Colour Maximum Current 1.15A@12VDC / 0.58A@24VDC Storage Temperature -40°C to +75°C Operating Temperature -30°C to +65°C Maximum Power 13.8W Synchronisation 15 Unit Sync LED Colour Blue LEDs Fuse Rating 2A Lens Colour Tinted Lens Compliance ECE R10, ECE R65 - XB1 Optic Type TIR Optics Nominal Voltage 12-24VDC Mounting Option Hood Mount Cable Type Cable (Pigtail) LED Quantity 6LED IP Rating IP67 Flash Patterns 5 Flash Patterns Wire Length 970mm Mounting Orientation Vertical Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
Mounting
-
