Specifications
Product Specifications
Product code 03040294 Product Name R0 Marker Lamp - Red Categories Warning Lights, Modules, R0 Mini Responder Product Type Products Dimensions Length/width 38mm (1.55") Dimensions Height 25mm (0.915") Dimensions Depth 11.8mm (0.5") Bezel Colour Chrome Colour Type Single Colour Maximum Current 0.06A@12VDC Storage Temperature -40°C - +75°C Operating Temperature -30°C~+65°C Maximum Power 0.72W LED Colour Red LEDs Fuse Rating 0.5A Lens Colour Clear Lens Compliance SAE J592 Class 1, SAE J595 Class 3 Input Voltage 12VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Elements 4x LEDs IP Rating IPX7 Flash Patterns 1 Flash Pattern Wire Length 310mm Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty - Downloads
