Specifications
Built-in 25 selectable flash patterns.
0.35″ (9mm) Super low-profile thickness.
Non-volatile memory recalls last flash pattern used at power up.
Weatherproof and vibration resistant design for internal or external use.
Multi-units synchronization in simultaneous or alternating flash.
LED rated to 100,000 hours of operation.
Aluminium base for heat dissipation.
Reverse polarity protection.Product Specifications
Product code 02160030 Product Name ST26 Warning Lighthead (Horizontal) - Red Categories Lighting, Super Thin, Directionals, Modules, ST26 Product Type Products Dimensions Length 115mm Dimensions Height 43mm Dimensions Width 9mm Colour Type Single Colour Maximum Current 1.56A@12VDC / 0.78A@24VDC Maximum Power 18.5W Synchronisation 15 Unit Sync LED Colour Red LEDs Fuse Rating 3A Lens Colour Clear Lens Compliance ECE R10, SAE J595 Class 1 Optic Type TIR Optics Nominal Voltage 12-24VDC Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Quantity 12LED IP Rating IPX8 Flash Patterns 25 Flash Patterns Wire Length 250mm Mounting Orientation Horizontal Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
