EAN: 06370015
Legion FIT H002 Speaker Lightbar, 1252mm (49.3″), 24x AMBER LEDs, AMBER LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 7 Flash Patterns, Single Harness (2 Function/2 Power/2 Speaker), Standard Feet, 12~24VDC.
-
Specifications
Built-in integrated speaker.
Built-in selectable flash patterns.
Easy maintenance and lighthead replacement.
Multi-voltage input 12-24VDC with EMC compliance.
Non-volatile memory recalls last flash pattern used at power up.
Solid aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06370015 Product Name Legion FIT H002 Speaker 1252mm (49.3") - AA (12~24VDC) Categories Warning Lamps, Lightbars, Legion FIT H002 Speaker, Legion FIT, Legion Product Type Products Configurations (available Cruise Light Dimensions Length 1252mm (49") Default Functions Hi/Low Power (50%, ECE-R65 Warning Mode Dimensions Height 76.7mm (3") Speaker Power Rating 100W Dimensions Width 331mm (13") Colour Type Single Colour Maximum Current 6.5A@12.8VDC / 3.4A@25.6VDC Lightbar Length 1252mm (49.3") Speaker Impedance 10-13 Ohms LED Colour Amber LEDs Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (TA1), SAE J845 Class 1, CA13 Input Voltage 12VDC~24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (2 Function/2 Power/2 Speaker) LED Quantity 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Net Weight 15.4kg Gross Weight 16.4kg Warranty 5 Year Warranty -
Spare Parts
-
-
- Lightheads
- Single Colour
- 3x LEDs
- 3 Pin Connector
- Amber LEDs
-
-
- 100W
- Acrylonitrile Butadiene Styrene (ABS), Aluminium
- 100W
- H002
- 10-13 Ohms
-
-
-
-
-
-
- Lightheads
- Single Colour
- 6x LEDs
- 3 Pin Connector
- Amber LEDs
-
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 6 Pin Connector
- Single Harness (6 Function/2 Power)
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- Standard Bolt Mount Brackets
- Black
-
