EAN: 06380144
Legion FIT Illuminated Centre Lightbar, 1087mm (42.8″), 24x AMBER LEDs, 18 WHITE ICS, CLEAR/OPAL LENSES, ECE R10, ECE R65 (TA1), IPX4K, Firmware (AK), D-Fuser Optics, Double Flash Warning, Single Harness (2 Function/2 Power), Standard Feet, 24VDC.
-
Specifications
Easy maintenance and lighthead replacement.
6 LED large d-fuser optics for corner lightheads.
Illuminated centre section with 3 LED backlight modules.
Non-volatile memory recalls last flash pattern used at power up.
Solid aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06380144 Product Name Legion FIT Illuminated Centre 1087mm (42.8") - AC (24VDC) Categories Warning Lamps, Lightbars, Legion FIT Illuminated Centre, Legion FIT, Legion Product Type Products Configurations (available Illuminated Centre Dimensions Length 1087mm (42.8") Default Functions ECE-R65 Warning Mode Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Single Colour Maximum Current 3.9A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1087mm (42.8") LED Colour Amber LEDs, White LEDs Lens Colour Clear Lens, Opal Lens Compliance ECE-R10, ECE-R65 (TA1), SAE J845 Class 1, CA13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (2 Function/2 Power) LED Quantity 36x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX4K Flash Patterns 1 Flash Pattern Net Weight 10.4kg Gross Weight 11.4kg Warranty 5 Year Warranty -
Spare Parts
-
-
- Lightheads
- Single Colour
- 3x LEDs
- 3 Pin Connector
- Fresnel Optics
-
- Lightheads
- ECE-R7
- Split Colour
- 12x LEDs
- Clear Lens
-
-
-
-
-
-
- Lightheads
- Single Colour
- 6x LEDs
- 3 Pin Connector
- D-Fuser Optics
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 4 Pin Connector
- Single Harness (2 Function/2 Power)
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- Standard Bolt Mount Brackets
- Black
-
